Fiberglass Reinforced Plastic FRP Cooling Tower Counterflow Type Customized Size
Product Details:
| Place of Origin: | ShanDong province,CHINA |
| Brand Name: | YONGDA |
| Model Number: | Customized |
Payment & Shipping Terms:
| Minimum Order Quantity: | one set,to be negotiated |
|---|---|
| Price: | $1800-23000/set，USD 1800-23000 per set ,to be negotiated |
| Packaging Details: | nude packing or bundled ，TEU or FR TEU ,to be negotiated |
| Delivery Time: | 15 days ，To be negotiated according order |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 10 set per week |
|
Detail Information |
|||
| Cooling Capacity: | 5-5000m3/h，Customized | Fan Diameter: | 300-5000mm,customized |
|---|---|---|---|
| Wind Resistance: | ≤300Pa | Noise Level: | ≤75dB |
| Water Outlet Temperature: | 25-35℃ | Operating Temperature: | 5-50℃ |
| Material: | Fiberglass Reinforced Plastic | Water Inlet Temperature: | 30-45℃ |
| Drift Loss: | ≤0.001% | Water Consumption: | 0.001-0.01m3/h |
| Type: | Crossflow/Counterflow | Installation: | Indoor/Outdoor |
| Warranty: | 1 Years | Power: | 0.18-500kw |
| Highlight: | fiberglass reinforced plastic frp tower,customized size counterflow cooling tower,frp cooling tower customized size |
||
Product Description
| Attribute | Value |
|---|---|
| Cooling Capacity | 5-5000m³/h, Customized |
| Fan Diameter | 300-5000mm, Customized |
| Wind Resistance | ≤300Pa |
| Noise Level | ≤75dB |
| Water Outlet Temperature | 25-35℃ |
| Operating Temperature | 5-50℃ |
| Material | Fiberglass Reinforced Plastic |
| Water Inlet Temperature | 30-45℃ |
| Drift Loss | ≤0.001% |
| Water Consumption | 0.001-0.01m³/h |
| Type | Crossflow/Counterflow |
| Installation | Indoor/Outdoor |
| Warranty | 1 year |
| Power | 0.18-500kW |
Our FRP Cooling Towers offer excellent cooling efficiency and are available in both square and round configurations with counterflow or crossflow designs. These towers are constructed from high-quality fiberglass reinforced plastic (FRP/GRP) materials that ensure durability and corrosion resistance.
- Anti-corrosion and durable FRP construction
- Lightweight design for easy transportation and installation
- Customizable sizes and configurations
- Energy efficient operation
- Low maintenance requirements
- Eco-friendly design with minimal water consumption
Our FRP Cooling Towers are suitable for various industrial applications including:
- Manufacturing plants
- Construction works
- Energy & Mining operations
- Chemical industry processes
- Commercial buildings
- Heat exchange systems
- Air conditioning and refrigeration systems
- Induction furnaces
- D.G. Sets
- Plastic molding machines
| Water inlet temperature design | 37℃ |
| Water outlet temperature design | 32℃ |
| Wet-bulb temperature design | 28℃ |
| Dry-bulb temperature design | 31.5℃ |
| Shape | Square, round, or customized |
| Core Components | Motor, Pump, Fan |
| Surface Treatment | Concave, smooth, or gritted |
| Packaging Details | Nude & bundled, TEU or FR TEU, as order |
| Port | QingDao, as order |
| Supply Ability | 1000 Set/Sets per Month |
| Lead Time | 1-10 sets: 15 days; >10 sets: To be negotiated |
- Customized logo (Min. order: 1)
- Customized packaging (Min. order: 1)
- Graphic customization (Min. order: 1)
Our square/round counter-current cooling towers intake air from the bottom and discharge waste heat at the top. The water travels from top to bottom while air passes from bottom to top, maximizing direct contact time between water droplets and air for efficient cooling. The wet cooling towers operate by evaporating a portion of the circulating water.
- Panel: FRP material, corrosion resistant with bright, clean surface
- Packing: Modified PVC or FRP two-way point wave for optimal thermal performance
- Fan: FRP or alloy aluminum blades for high efficiency and low noise
- Motor and reducer: External equipment for reliable operation
- Skeleton: Galvanized steel assembly structure for durability and corrosion resistance
Weifang Yongda FRP Co., Ltd., founded in 2009, is a professional manufacturer specializing in glass fiber reinforced thermosetting plastic and other composite materials. We offer comprehensive R&D, production, sales, and service for a wide range of FRP products including pipes, purification towers, environmental protection equipment, and cooling towers.
WeiFang YongDa FRP Co., Ltd
We are a factory and a professional manufacturer of FRP products with more than 50 skilled technicians and professional mold engineers for design and production.
West side of the road about 3 kilometers north of Wenhe Bridge Toll Station on National Highway 206, Ying qiu Town, Chang Le County, Weifang City, Shandong Province, China. We can arrange pick-up for visiting customers.
We maintain ISO9001:2015 quality control system with professional QC team and final inspection before packing.
Yes, we accept all OEM orders. Contact us with your design for a customized quote.
T/T, L/C, Western Union
