FRP GRP Material Bromine Absorption Tower Anti Corrosion For Chemical Industry
Product Specifications
| Attribute | Value |
| Application | bromine production |
| Product name | Bromine tower |
| Core components | Pressure vessel |
| Dimension | Customized |
| Extraction efficiency | 90% |
| Color | Customized |
| Material | FRP |
| Feature | Anti corrosion |
| Function | Field maintenance and repair service |
Product Description
FRP GRP Distillation Process Chemical Industry Bromine Extraction Tower Energy Efficient High Quality Bromine Tower
Technical Specifications
| Application | Industry, chemical industry, foundry industry, high pollution industry |
| Technique | Winding, hand layup |
| Dimension | Customized |
| Surface Treatment | Smooth, customized |
| Material | Fiber Reinforced Plastic, FRP GRP |
| Brand Name | YongDa |
| Place of Origin | Shandong province, CHINA |
| Automatic Grade | Semi-automatic |
Packaging & Delivery
| Packaging Details | Bundled, nude, as order |
| Port | QingDao or Customized |
Supply Information
| Selling Units | Single set |
| Supply Ability | 1 Set per Week |
Lead Time
| Quantity (sets) | 1 | >1 |
| Lead Time (days) | 15 | To be negotiated |
Customization Options
- Customized logo (Min. order: 1)
- Customized packaging (Min. order: 1)
- Graphic customization (Min. order: 1)
Production Process
Unlike the United States and Israel, which use natural salt lake with high bromine concentration (2,000-12,000 ppm) as the raw material for bromine preparation, China's bromine production is mainly based on the direct extraction of bromine from the medium brine and underground brine as the raw material before salt production, and the bromine content of the medium brine and underground brine before salt production is in the range of 250-350 ppm, which is low in yield and high in cost.
Process Flow
Bromine manufacturers use seawater as the source of brine, after natural evaporation and conditioning, the bitter brine is produced and obtained. Use the pump to extract the brine, add the dilute acid and chlorine gas successively from the brine pump outlet pipe, the bromide in the brine in the pipe is oxidized by the acid and chlorine into the single bromine, and the brine is sent to the top of the blow-out tower through the pipe.
Bromine manufacturers will oxidized brine from the top of the blowing tower spray down, and circulating gas in the tower packing surface contact, monomaterial bromine is blown from the top of the tower, debromination of brine from the bottom of the blowing tower discharged, sent out of the brine in a large number of salts, can be used as raw materials for solar salt.
The bromine-containing gas blown from the top of the tower reacts with the sulfur dioxide and foggy fresh water added in the top duct to generate hydrobromic acid and sulfuric acid. Small droplets containing hydrobromic acid and sulfuric acid are enriched by the foam trap of the absorption tower and coalesce into liquid, which flows into the completion liquid storage tank from the bottom of the tower.
Company Profile
Weifang Yongda FRP Co., Ltd. was founded in 2009, is a professional engaged in glass fiber reinforced thermosetting plastic and other new composite materials research and development, production, sales, service, a comprehensive scale of four-in-one enterprise!
The company's main products: FRP pipes, pipe fittings, FRP purification tower series, biological deodorization filter tank, environmental protection equipment, exhaust gas treatment system, activated carbon adsorption tank, septic tank, cooling tower series, storage tanks, equipment tanks, aquaculture equipment, equipment shrouds, and to undertake anticorrosive engineering, thermal insulation engineering, VOCs purification project.
Frequently Asked Questions
Q1: What is your company name?
WeiFang YongDa FRP Co., Ltd
Q2: Are you a factory or a trading company?
We are a factory and a professional manufacturer of FRP products. We have more than 50 skilled technicians. In addition, we have professional mold engineers for design and production.
Q3: Where is your factory? How can I visit you?
West side of the road about 3 kilometers north of Wenhe Bridge Toll Station on National Highway 206, Ying qiu Town, Chang Le County, Weifang City, Shandong Province, China. If you come to our factory, I will arrange a pick-up for you so that we can meet up faster.
Q4: How can you guarantee the product quality?
We have the quality control system ISO9001:2015, and it's been followed strictly. We also have the professional QC team, and each our package worker will be in charge of the final inspection according to the QC instruction before packing.
Q5: Can you do OEM for me?
We accept all OEM orders, just contact us and give me your design, we will offer you a reasonable price ASAP.
Q6: What payment methods do you support?
T/T, L/C, western union
